Autoclave Bicycle Tube

Category Tag

The Autoclave tube is different from the heat-molded tube. The autoclave tubes which can be produced easier have become less common over the past years. But it’s still popular in Gambia Market. Ifan autoclave tube high air retention and elasticity. This high elasticity allows a wide range of different tire sizes to be covered.

Additional information

Size

10—29 inches

package

Color box, Plastic Shinking bag

Valve

AV, AV40mm, DV, DV40mm, FV, FV40mm, FV60mm, FV80mm

Others

Other information, please check below product details.

Structure&Process

The butyl inner tube formula includes several parts: skeleton material, filler, vulcanization system, processing aid, anti-aging agent
  • The skeleton materials mainly include butyl rubber, butyl rubber reclaimed rubber, and EPDM rubber.
  • The main fillers are carbon black, calcium rubber, etc.
  • Vulcanization system: The vulcanization system of the butyl inner tube is more complicated and should be adjusted according to equipment and process conditions. The vulcanization system is mainly M+TT.
  • Processing aids: mainly paraffin oil, if necessary, add some tackifying resins, etc., stearic acid, ointment, and other lubricants can also be used.
  • Anti-aging agent: Mainly use 4020, 4010NA and paraffin, etc.
  • Every tube also needs a valve, which is bonded to the tube during the vulcanizing process.
Rubber Mixing–Filter–Extrusion–Joint–Vulcanize–Inspection–Fold–Packing

Product details:

BASIC INFORMATION



Product Butyl Bicycle Tube Palce of Origin Jiangsu, China
OEM Yes Warantee 2 years
Brand Ifan Material Butyl Rubber
Quality A Grade Color Black
Production Capacity 1,500,000pcs/month Delivery Time 30–40 days



POPULAR VALVE TYPE

  • DV     Bicycle, Woods, Hollands. Length 26.5 mm or 40 mm.

POPULAR ITEM LIST



Size weight g width mm package Pieces/CTN
16x2x1 3/4 DV-26.5mm 192 55mm Blister bags+label 120pcs
20x2x1 3/4 DV-26.5mm 247 55mm Blister bags+label 120pcs
24x2x1 3/4 DV-26.5mm 260 55mm Blister bags+label 120pcs
26x2x1 3/4 DV-26.5mm 302 55mm Blister bags+label 120pcs
26x2x1 3/4 DV-40mm 305 55mm Blister bags+label 120pcs
28×1 1/2 DV-26.5mm 236 38mm Blister bags+label 120pcs
